Websocket Integration with Node

2/25/21 12:03 PM

Websocket Integration with Node

EveryOne building realTime apps with Socket.IO these days. Think a moment about it: There are a million other things that are built based on real-time applications. Do you want to build your own app with real-time updates? Let’s have a look at the basic configuration to build socket communication apps using Node and React Js.

List of things that we will learn from this blog

  • What is Socket programming
  • How to configure socket with Node and react js

Presumption: Before we proceed further, I assume that you have basic knowledge of NodeJs and reactJs

What is Socket programming
  • Socket is an internet communication protocol that provides bi-direction communication on top of TCP protocol
  • Using WebSocket, Client and Server can communicate with each other in a real-time manner.
  • Once the client is connected to the server, the client can receive data from the server without the need to continuously refresh the web page
  • Server can also receive data from client within the same connection
Configuration of socket with Node and React Js
  • Let’s create one directory with name Socket_connection_app

    mkdir socket_connection_app && cd  Socket_connection_app
  • Initialize node project using below command, Which will create package.json file for you
    • npm init
  • We need to install express and socket.io package from node package manager
    • npm i express
    • npm i socket.io
  • Create app.js file on your project directory with will hold the actual server

const express = require("express");

const http = require("http");

const socketIo = require("socket.io");


const port = 8080;

const route = require("./routes/index");


const app = express();

app.use(route);


const server = http.createServer(app);

const io = socketIo(server);
  • I hope you are aware with Node js and this code is not looking magic words to you
    • We can initialize Socket server by passing server object on defined variable socketIo
    • We also define an index route on our app. Even though we are not serving any HTML content to the client. It is necessary for a very simple route to listen for any incoming connection.
  • Now, create index.js file inside a routes directory :

const express = require("express");

const router = express.Router();

router.get("/", (req, res) => {

  res.send({ response: "I am alive" }).status(200);

});


module.exports = router;
  • I hope you are aware with Node js and this code is not looking a magic Designing socket
  • While configuring the socket server, the most important method we can see is on. It takes two-argument, first one is a type of event and the second one is event callback for every connection event
  • Connection event returns a socket object which will be passed to the callback function and by using this socket object server can send data back to the client.

let interval;


io.on("connection", (socket) => {

  console.log("New client connected");

  if (interval) {

    clearInterval(interval);

  }

  interval = setInterval(() => getApiAndEmit(socket), 1000);

  socket.on("disconnect", () => {

    console.log("Client disconnected");

    clearInterval(interval);

  });

});
  • Let’s improve getApiAndEmit method which will generate the message that can be send to the client

let interval;


io.on("connection", (socket) => {

  console.log("New client connected");

  if (interval) {

    clearInterval(interval);

  }

  interval = setInterval(() => getApiAndEmit(socket), 1000);

  socket.on("disconnect", () => {

    console.log("Client disconnected");

    clearInterval(interval);

  });

});
App.js File Example

const express = require("express");

const http = require("http");

const socketIo = require("socket.io");


const port = process.env.PORT || 4001;

const index = require("./routes/index");


const app = express();

app.use(index);


const server = http.createServer(app);


const io = socketIo(server);


let interval;


io.on("connection", (socket) => {

  console.log("New client connected");

  if (interval) {

    clearInterval(interval);

  }

  interval = setInterval(() => getApiAndEmit(socket), 1000);

  socket.on("disconnect", () => {

    console.log("Client disconnected");

    clearInterval(interval);

  });

});


const getApiAndEmit = socket => {

  const response = new Date();

  // Emitting a new message. Will be consumed by the client

  socket.emit("FromAPI", response);

};

server.listen(port, () => console.log(`Listening on port ${port}`));
  • To start the node server use below command for the same
    • To start the node server use below command for the same
Let’s implement the front end for second-hand communication(using react Js)
  • Create react js app
    • npx create-react-app socket_connection_app
  • Install socket client on your front end app
    • npm i socket.io-client
  • To make a simple structure, Let’s create an app.js file in the src directory

import socketIOClient from "socket.io-client";

const ENDPOINT = "http://127.0.0.1:8080";


function App() {

  const [response, setResponse] = useState("");


  useEffect(() => {

    const socket = socketIOClient(ENDPOINT);

    socket.on("FromAPI", data => {

      setResponse(data);

    });

  }, []);


  return (

    <p>

      It's <time dateTime={response}>{response}</time>

    </p>

  );

}


export default App;
  • Start the react server and you can see the timestamp getting update every second by the magic of the socket
    • cd socket_connection_app
    • npm start
